Pin-type adjustable steel prop is a fast-locking telescopic support for construction formwork. Made of Q235B/Q345B steel with painted or galvanized surface. It adopts pin positioning structure for quick height adjustment and locking, featuring simple operation, stable bearing and high efficiency. Widely used in concrete formwork shoring, floor beam support, building reconstruction and temporary load-bearing projects. Pin-type adjustable steel prop is a new generation of rapid adjustment temporary steel support, widely matched with modern formwork systems in construction industry. Different from traditional threaded props, this product uses pin hole positioning and safety pin locking structure, which realizes fast height adjustment and instant fixation without rotating nuts repeatedly. It greatly saves on-site operation time and effectively improves construction progress, becoming an ideal supporting tool for high-efficiency construction projects. The whole prop consists of outer tube, inner tube, positioning pin holes, safety lock pin, top plate and base plate. We select high-quality Q235B carbon steel as standard material, and Q345B high-strength steel is optional for heavy load conditions. Both inner and outer tubes are processed by high-frequency welding or seamless pipe, with uniform wall thickness and excellent compression resistance. The dense pin holes are precisely punched on the inner tube with equal spacing, ensuring accurate height gear adjustment and uniform force bearing at each position. All connecting parts between pipe body and end plates adopt full penetration welding, with smooth and firm welds, no cracking or deformation under long-term heavy pressure. Standard outer tube diameters include 48mm, 56mm and 60mm, and wall thickness ranges from 1.8mm to 3.5mm to cover light, medium and heavy load grades. The adjustable height ranges from 1.5m to 5.8m, meeting the height requirements of most indoor floors, beams, slabs and foundation formwork. For surface treatment, we provide anti-rust painting, pre-galvanizing and hot-dip galvanizing. Painted type is economical for short-term use, while galvanized products have superior anti-corrosion performance, suitable for repeated use in humid, outdoor and harsh environments. The safety lock pin is made of thickened solid steel, which can be inserted into the pin hole quickly to fix the inner tube firmly. It effectively prevents accidental retraction and displacement, ensuring overall structural stability and construction safety. This prop has reasonable force distribution, strong anti-bending performance and long service life, and can be reused many times. All products have passed professional compression test and mechanical performance test, complying with international construction temporary support standards. It is widely applied in cast-in-place concrete formwork support, building beam and slab shoring, tunnel formwork, temporary support for renovation and demolition works. With simple structure, lightweight body and convenient transportation and stacking, pin-type steel props are deeply favored by construction teams and formwork rental companies. We adopt standard export packaging with steel strapping to avoid damage during long-distance transportation. With reliable quality, fast adjustment and competitive cost, our pin-type adjustable steel props are exported to many countries and regions. Product Features: Pin hole positioning & lock pin structure, fast height adjustment and instant locking. No need for repeated rotation, simple operation and high working efficiency. Made of Q235B/Q345B steel, high compression resistance and strong load capacity. Dense equidistant pin holes, accurate height gears and uniform force bearing. Full welding design for pipe and plates, firm structure, not easy to deform. Thickened safety pin, anti-retraction and anti-slip, high construction safety. Multiple surface treatments: painted, pre-galvanized and hot dipped galvanized. Various pipe diameters and wall thicknesses for light, medium and heavy duty. Wide adjustable height range, suitable for different construction scenarios. Reusable, easy to store and transport, cost-effective for long-term use. Frequently Asked Questions (FAQ): Q: What is pin-type adjustable steel prop?A: It is a fast-locking telescopic steel support with pin hole structure, used for concrete formwork and temporary structural support on construction sites. Q: What materials do you use?A: Standard material is Q235B carbon steel; Q345B high-strength steel is available for heavy load projects. Q: What are the standard specifications?A: Tube outer diameter: 48mm/56mm/60mm; Adjustable height: 1.5m – 5.8m. Q: What surface options are available?A: We supply anti-rust painted, pre-galvanized and hot dipped galvanized finishes. Q: What is your MOQ and delivery time?A: MOQ is 100 Ton, delivery time 7–15 days after deposit.

Item	Specification
Product Name	Pin-Type Adjustable Steel Prop / Pin Lock Telescopic Steel Support
Material Grade	Q235B (Standard), Q345B (Heavy Duty)
Production Process	Pipe Cutting → Punching Holes → Welding → Surface Anti-rust Treatment
Executive Standard	International Construction Temporary Support Standard
Tube Outer Diameter	48mm / 56mm / 60mm
Tube Wall Thickness	1.8mm – 3.5mm
Adjustable Height Range	1.5m – 5.8m
Main Components	Outer Tube, Inner Tube, Positioning Holes, Safety Lock Pin, Top & Base Plate
MOQ	100 Ton
Delivery Time	7-15 Days
Surface Finish	Anti-rust Painted / Pre-galvanized / Hot Dipped Galvanized
